Shacman H3000 8X4 Concrete Mixer Truck
✅ Detailed Description
Power & Transmission:
The Shacman H3000 features a WP12.450E201 diesel engine delivering 280 kW and 1500 N·m torque. It is paired with a 10JSD180 transmission and PTO system for stable power delivery and smooth concrete pumping. The engine meets Euro II emission standards, balancing performance with environmental compliance.
Structure & Load Capacity:
Built on a robust 850×300 mm frame, the 8×4 platform supports up to 50 tons of concrete. The 12 m³ wear-resistant mixing drum ensures consistent quality, while reinforced multi-leaf suspension and MAN front/rear axles provide stability under full load. The compact hydraulic circuit and temperature-controlled system maintain efficiency and prevent overheating during long operations.
Cabin & Operational Use:
The ergonomic driver cabin includes a hydraulic seat, manual sunroof, automated air conditioning, and entertainment options. Rear visibility is enhanced with a rear window, while safety features include seat belts, ABS-ready options, and optional air-cushioned driver seat. The vehicle is ideal for highways, urban construction, and large-scale projects across Africa, the Middle East, and other export markets.
✅ Key Specifications
| Specification | Details |
|---|---|
| Transport Type | Heavy haul transportation |
| Logistics Type | Concrete |
| Drive | 8×4 |
| Max Weight (t) | ≤50 |
| Load/Volume (m³) | 12 |
| Max Speed (km/h) | 85 |
| Loaded Speed (km/h) | 45–60 |
| Vehicle Model | SX5315GIBHU306 |
| Engine | WP12.450E201 + PTO |
| Emission Standard | Euro II |
| Displacement (L) | 11.26 |
| Rated Output (kW) | 280 |
| Max Torque (N·m) | 1500 |
| Transmission | 10JSD180 |
| Clutch | 430 |
| Frame | 850×300 (8+7) |
| Front Axle | MAN 9.5T |
| Rear Axle | 16T MAN double reduction 5.262 |
| Tires | 12.00R20 |
| Front Suspension | Multi leaf springs |
| Rear Suspension | Multi leaf springs |
| Fuel | Diesel |
| Fuel Tank Capacity (L) | 400 |
| Dimensions (L×W×H mm) | 10725×2495×3774 |
| Approach/Departure Angle (°) | 20/18 |
| Max Grade Ability (%) | 34 |
| Cabin Features | Rear window, manual sunroof, hydraulic seat, automated AC, electric window, radio with MP3 |
| Optional Equipment | Air cushioned seat, full WABCO valve, central locking |
